460
Appendix
String function
Numerical Calculation
Judge. Meaning of function
Statistics
Result
SMCnnn_TEMP.mmm
@ (Type2)
Yes
Smart Matching
Detect Template No.
SMCnnn_TIME
@ (Type2)
Yes
Smart Matching
Inspection Time
SMCnnn_X.mmm
@ (Type2)
Yes
Smart Matching
X
SMCnnn_Y.mmm
@ (Type2)
Yes
Smart Matching
Y
SORT(
Yes
The value of the number specified by the
fourth term in parentheses when sorting the
number of Calculation Nos. specified by the
second term from the Numerical
Calculation No. specified by the first term in
the order specified by the third term
(0=descending, 1=ascending).
SQRT(
Yes
Square root of a value in parentheses
SUM(
Yes
Sum of the calculation results for the
number specified by the second term in
parentheses from the Numerical
Calculation No. specified by the first term.
SYS:REG0
Yes
System Register 0
SYS:REG1
Yes
System Register 1
SYS:REG2
Yes
System Register 2
SYS:REG3
Yes
System Register 3
SYS:REG4
Yes
System Register 4
SYS:REG5
Yes
System Register 5
SYS:REG6
Yes
System Register 6
SYS:REG7
Yes
System Register 7
SYS_COUNT
Yes
Scan Count
TAN(
Yes
Tangent when the value in parentheses is
radian
TAND(
Yes
Tangent when the value in parentheses is
degree
VDIST(
Yes
Length of a perpendicular to a line through
a point expressed by five values in
parentheses
VPOINTX(
Yes
X of the foot of a perpendicular to a line
through a point expressed by five values in
parentheses
VPOINTY(
Yes
Y of the foot of a perpendicular to a line
through a point expressed by five values in
parentheses
