6901 Keypad
890CS Common Bus Supply
The 6901 Keypad (Man-Machine Interface, MMI)
provides for local control (power-up/power-down),
and also monitoring of the five diagnostics
provided on the display.
To display the Software Version & Voltage
Rating:
Press and hold
to display software version.
Time-out or press
.
To Stop in
Local Mode:
Press
To Start in
Local Mode:
Press
Initial Powe
r
-Up Conditions
The unit will always power-up in Remote mode.
The Keypad will display the DC Link Power
on the 890CS Common Bus Supply.
E
M
PROG
L
R
Programming
Keys
Local
Control
Keys
JOG
1
DC 4Q 15A
D C
D I V R E I I T G A L D
OK SEQ REF
1
15kW 400V 1.x
A C D I V R E O T O R M
