Parker 890SD - Display Indications

The Keypad
Page 8-18 890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
8
9
10
11
A
B
C
D
1
2
3
4
5
6
7
E
Display Indications
Indicates the
Control Mode
Represents a rotating shaft:
clockwise = drive running forward
anticlockwise - drive running in reverse
Indicates numbers or values,
trip information, error codes etc.
See "Status Indications" below.
Indicates the drive is in Local control.
Drive is in remote control when not visible.
Displays the units for the value:
for voltage in Volts,
for frequency in Hertz
for current in Amps
for percentage
V
Hz
S
A
%
when displaying an Alarm code
a negative parameter value
for seconds
Indicates the
drive is in
Remote
Comms
mode
