Electrical Ratings: 890CD Frame C, 380-500V
Input currents listed at 560V DC and 650V DC assuming total source impedance of 800μH. Motor power, input current and
output current must not be exceeded under steady state operating conditions.
Model Number
890CD/5/0024C 890CD/5/0030C 890CD/5/S030C
Nominal Supply Voltage
560Vdc 650-705Vdc 560Vdc 650-705Vdc 560Vdc 650-705Vdc
Motor Power 11kW 15Hp 15kW 20Hp
15kW 20Hp
External Continuous Power Rating W 4000 4000 5000 5000
5000 5000
Vector Mode
Input Current A 33 28 43 36 43 36
Output Current @ 3kHz A 24 24 30 27 30 30
Power Loss @ 3kHz W 190 190 250 230 250 260
Output Current @ 6kHz A 22 22 25 24 26 25
Power Loss @ 6kHz W 200 210 280 220 290 300
Output Overload Motoring 150% overload for 60 seconds
Servo Mode
Input Current A 27 23 36 32
43 34
Output Current @ 4kHz A 20 20 25 22 30 28
Power Loss @ 4kHz W 180 190 230 210 280 280
Output Current @ 8kHz A 16 14 18 16 20 18
Power Loss @ 8kHz W 170 170 210 220 280 290
Output Overload Motoring 200% overload for 4 seconds
