Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D Page D-11
8
9
10
11
B
C
D
1
2
3
4
5
6
7
E
AUTO RESTART
SETUP::SEQ & REF::AUTO RESTART
Auto Restart provides the facility to automatically reset a choice of trip events and restart the Drive with a programmed
number of attempts, after which, a manual or remote trip reset is required if the Drive is not successfully restarted. The number
of attempted restarts are recorded. This count is cleared after a trip-free period of operation (5 minutes or 4 x ATTEMPT
DELAY 1, whichever is the longer), or after a successful manual or remote trip reset, or by removing the Run signal, or by
setting the ENABLE input to this block FALSE.
Parameter Descriptions
ENABLE
PREF: 93.01
Default: FALSE Range: FALSE / TRUE
Enables operation of the auto restart feature. TRUE = enabled.
ATTEMPTS
PREF: 93.02 Default: 5 Range: 1 to 10
Determines the number of restarts that will be permitted before requiring an external fault reset.
INITIAL DELAY 1
PREF: 93.03 Default: —.x s Range: 0.0 to 600.0 s
Determines the delay for the first restart attempt when the trip is included in TRIGGERS 1 .
The delay is measured from all error conditions clearing.
ATTEMPT DELAY 1
PREF: 93.04 Default: —.x s Range: 0.0 to 600.0 s
Determines the delay between restart attempts for a trip included in TRIGGERS 1 . The delay is measured from all error
conditions clearing.
TRIGGERS 1 and
TRIGGERS 1+
PREF:93.05, 93.06 Default: 0000 Range: 0x0000 to 0xFFFF
Allows Auto Restart to be enabled for a selection of trip conditions. Refer to TRIPS STATUS, page D-142, for an explanation
of the four-digit codes.
