2.3 Device identification
2.3.2 S31_S39
15
2.3.2 S31_S39
Device identification.
Object Description
Index
0x5fd6
Symbol
S31-S39
Length
6
Access groups
0
Object code
Array
Elements
9
Password
0
Data type
Octet string
Access rights
Read all
PD Map
Not possible
Data Description
Coding
BCD
Value range
000000000000 ... 999999999999
Data byte [Bit] Assignment Data byte [Bit] Assignment
1 [7,6,5,4]
10
11
4 [7,6,5,4]
10
5
1 [3,2,1,0]
10
10
4 [3,2,1,0]
10
4
2 [7,6,5,4]
10
9
5 [7,6,5,4]
10
3
2 [3,2,1,0]
10
8
5 [3,2,1,0]
10
2
3 [7,6,5,4]
10
7
6 [7,6,5,4]
10
1
3 [3,2,1,0]
10
6
6 [3,2,1,0]
10
0
Sub-index Assignment Sub-index Assignment
1 Software version 6 Date, version of bus option
2 Software date 7 Device identification
3 Job number 8 Device family
4 Part number 9 Device
5Version
In Sub-index 2 and 6, the data bytes are assigned as follows:
Data byte
123456
Assignment
Day Month Year Version Identifier
