Page #36 background image
2. Object index
Interbus-S
36
2.7.8 REALNULL
Reference measurement offset.
Difference between real null point and machine zero point.
After the reference run, all positioning processes refer to the real null point.
Object Description
Index
0x607c
Symbol
REALNULL
Length
4
Access groups
0
Object code
Simple var.
Password
0
Data type
Integer32
Access rights
Read/write all
PD Map
Not possible
Data Description
Unit
mm (or inch)
Resolution
1
0.001 mm (or inch)
Example
The real null point should be -500.000 mm.
Service
Write request
Sub-index
0
3. data byte
0x5e
Command Code
0x8082
Length
4
4. data byte
0xe0
Param. counter
5
1. data byte
0xff
Index
0x607c
2. data byte
0xf8
2.7.9 GRENZEN
Position limit value min-max.
The position limit values are software end limits and correspond to the absolute position limits, within which the set values and
actual values (in absolute form) must be moved. Each new target position is checked with these limits. They always refer to the
machine zero point; therefore they must be corrected using the reference measurement offset.
Object Description
Index
0x607d
Symbol
GRENZEN
Length
4
Access groups
0
Object code
Array
Elements
2
Password
0
Data type
Integer32
Access rights
Read/write all
PD Map
Not possible
Data Description
Unit
mm (or inch)
Resolution
1
0.001 mm (or inch)
Sub-index Assignment Sub-index Assignment
1 Negative limit stop 2 Positive limit stop
Note the number range for the Integer32 formats (see page 9 under "1.7.2 Integer").
Limits outside -2 147 483 - +2 147 483 units cannot be depicted.
Example
The position limit value min. (neg. limit stop) is set at -1650.000 mm.
Service
Write request
Sub-index
1
3. data byte
0xd2
Command Code
0x8082
Length
4
4. data byte
0x0b
Param. counter
5
1. data byte
0xff
Index
0x607d
2. data byte
0xe6
