Parker Hauser COMPAX-M Series Interface Manual

2. Object index
Interbus-S
60
2.11.3 GOTO
Set and read record pointer.
Object Description
Index
0x5ff2
Symbol
GOTO
Length
1
Access groups
0
Object code
Simple var.
Password
0
Data type
Unsigned8
Access rights
Read/write all
PD Map
Not possible
Data Description
Data format
Binary
Unit
Record number
Value range
1 ... 250
Resolution
1
Example
The record pointer is set to command record 18.
Service
Write request
Index
0x5ff2
Data byte
0x12
Command Code
0x8082
Sub-index
0
Param. counter 4
Length
1
2.11.4 START_N
Run program record N.
Only this record is processed. The record pointer remains at this program record.
Object Description
Index
0x5ff4
Symbol
START_N
Length
1
Access groups
0
Object code
Simple var.
Password
0
Data type
Unsigned8
Access rights
Write all
PD Map
PAD
Data Description
Data format
Binary
Unit
Record number
Value range
1 ... 250
Resolution
1
Example
Program record 26 must be processed.
Service
Write request
Index
0x5ff4
Data byte
0x1a
Command Code
0x8082
Sub-index
0
Param. counter
4
Length
1
