Parker Hauser COMPAX-M Series Interface Manual

Interbus-S
78
2.12.5 OUT_ENABLE
Enable process output data.
This parameter is allocated to the 1
st
(3
rd
)
12
byte of the process output data channel.
Meaning:
"OUT_ENABLE" = FALSE the corresponding process data value is disabled
"OUT_ENABLE" = TRUE the corresponding process data value is enabled
Object Description
Index
0x5fff
Symbol
OUT_ENABLE
Length
1
Access groups
0
Object code
Simple var.
Password
0
Data type
Boolean
Access rights
read/write all
PD Map
not possible
Data Description
Data byte Function Data byte Function
= 0x00 (FALSE) Process data value disabled = 0xff (TRUE) Process data value enabled
Example
The process data value which assigns 1
st
(3
rd
) byte of the PA data (and if necessary the others) should be enabled.
Service
Write request
Index
0x5fff
Data byte
0xff
Command Code
0x8082
Sub-index
0
Param. counter
4
Length
1
12
Die PD - Nummern in der Klammer gelten bei einer PD-Length von 8 Byte (P196 Bit 0...2 = "4").
