Parker Hauser COMPAX-M Series Interface Manual

2.7 Positioning
2.7.5 LAGE_IST
35
2.7.5 LAGE_IST
Position actual value.
Current drive position.
Object Description
Index
0x6064
Symbol
LAGE_IST
Length
4
Access groups
0
Object code
Simple var.
Password
0
Data type
Integer32
Access rights
Read all
PD Map
PED
Data Description
Unit
mm (or inch)
Resolution
1
⇔
0.001 mm (or inch)
2.7.6 S2
Target position.
End position of the current or last positioning cycle implemented.
Object Description
Index
0x5fdf
Symbol
S2
Length
4
Access groups
0
Object code
Simple var.
Password
0
Data type
Integer32
Access rights
Read all
PD Map
Not possible
Data Description
Unit
mm (or inch)
Resolution
1
⇔
0.001 mm (or inch)
2.7.7 S12
Position of the absolute value sensor (Option A1).
Object Description
Index
0x5fd9
Symbol
S12
Length
4
Access groups
0
Object code
Simple var.
Password
0
Data type
Integer32
Access rights
Read all
PD Map
Not possible
Data Description
Unit
mm (or inch)
Resolution
1
⇔
0.001 mm (or inch)
