2. Object index
Interbus-S
74
2.12.8 PA_ENABLE
Enable process output data.
Each bit of this parameter is associated with a byte of the process output data channel.
Meaning:
Bit = 0 the corresponding process data value is disabled
Bit = 1 the corresponding process data value is enabled
If an object takes up several bytes on the PA data channel, the logic state of the bit which is associated with the first byte of this
object is the one used, and the other associated bits are not relevant.
Object Description
Index
0x6002
Symbol
PA_ENABLE
Length
1
Access groups
0
Object code
Simple var.
Password
0
Data type
Octet string
Access rights
Read/write all
PD Map
Not possible
Data Description
Bit Assignment Bit Assignment
7 ="1": autom. Acceptance of a
modified LAGE_ZIEL of the PA
data is disabled
34
th
(6
th
) byte of the PA data
6 None 2 3
rd
(5
th
) byte of the PA data
5
6
th
(8
th
)
8
byte of the PA data
12
nd
(4
th
) byte of the PA data
45
th
(7
th
) byte of the PA data 0 1 (3
rd
). byte of the PA data
Bit Function Data byte Function
= 0 (FALSE) Process data value disabled = 1 (TRUE) Process data value enabled
Example
The process data value which assigns the 3
rd
(5
th
) byte of the PA data (and other if applicable) should be enabled.
The other process data values are disabled.
Service
Write request
Index
0x6002
Data byte
0x04
Command Code
0x8082
Sub-index
0
Param. counter
4
Length
1
8
The PD numbers in brackets are valid for a PD length of 8 bytes (P196 Bit 0...2 = "4").
