Parker Hauser COMPAX-M Series Interface Manual

2. Object index
Interbus-S
44
2.8.6 DREHZAHLMAX
Maximum motor speed value.
The maximum speed is given for both directions of rotation with a resolution of 1 rpm.
These are for the protection of the motor and can be found in the motor data sheet.
Object Description
Index
0x6080
Symbol
DREHZAHLMAX
Length
2
Access groups
0
Object code
Simple var.
Password
0
Data type
Unsigned16
Access rights
Read/write all
PD Map
Not possible
Data Description
Unit
Rpm
Resolution
1
⇔
1 rpm
Example
The max. speed of the motor is 6000 rpm.
Service
Write request
Index
0x6080
1. data byte
0x17
Command Code
0x8082
Sub-index
0
2. data byte
0x70
Param. counter
4
Length
2
2.8.7 GESCHW_MAX
Maximum speed
The maximum speed applies to both rotation directions.
Object Description
Index
0x607f
Symbol
GESCHW_MAX
Length
4
Access groups
0
Object code
Simple var.
Password
0
Data type
Unsigned32
Access rights
Read/write all
PD Map
Not possible
Data Description
Unit
%
Resolution
1
⇔
0.001 %
Example
The maximum speed is set to 95% of the nominal speed.
Service
Write request
Sub-index
0
3. data byte
0x73
Command Code
0x8082
Length
4
4. data byte
0x18
Param. counter
5
1. data byte
0x00
Index
0x607f
2. data byte
0x01
