Parker Hauser COMPAX-M Series Interface Manual

2. Object index
Interbus-S
24
2.4.13 Px
Read/write COMPAX parameters in binary format.
The corresponding parameter is selected using the Sub-index (Sub-index = parameter No.).
Object Description
Index
0x5fd4
Symbol
Px
Length
4
Access groups
0
Object code
Array
Elements
250
Password
0
Data type
Integer32
Access rights
Read/write all
PD Map
Not possible
Data Description
Parameter Resolution Parameter Resolution
001 .. 005
1
⇔
0.001
035 .. 036
1
⇔
0.000001
006 .. 010 1 037 .. 049 1
⇔
0.001
011 .. 016 1
⇔
0.001 050 .. 072 1
017 .. 020 1 073 .. 099 1
⇔
0.001
021 .. 022 1
⇔
0.000001 100 .. 186 1
023 .. 029 1 187 .. 196 1
⇔
0.001
030 .. 034 1
⇔
0.001 197 .. 250 1
Example
Parameter 11 must be given the value 5000.
Service
Write request
Sub-index
11
3. data byte
0x4b
Command Code
0x8082
Length
4
4. data byte
0x40
Param. counter
5
1. data byte
0x00
Index
0x5fd4
2. data byte
0x4c
