2. Object index
Interbus-S
28
2.5.8 S
All Compax status values that exist for the RS232 interface can be read with this object. The response is made available in plain
text (as ASCII string).
The corresponding status is selected using the Sub-index (Sub-index = status No.).
Object Description
Index
0x5fe8
Symbol
S
Length
32
Access groups
0
Object code
Array
Elements
250
Password
0
Data type
Visible-String
Access rights
read all
PD Map
not possible
Data Description
Coding
ASCII
Value range
0x20 ... 0x7f
Data byte Assignment Data byte Assignment
1 1. character of the response string 32 32. character of the response string
Example
Read S23.
Service
Read Request
Param. counter
3
Sub-index
23
Command Code
0x8081
Index
0x5fe8
