® Remove E93 x2, CNM1.7
x3
.0, El
JO
(Curtain shaft pedestal).
@ Remove E93, E97 (Shaft plate A retainer screw), CNS 1.7 x4.5.
@ Remove Shutter curtain block from the Mirror box.
NE93
12. Remove D23 (Magnet plate retainer screw),
CNL-Dl.7
x3.0
and
take D59 (Magnet plate).
023
13
. Remove E93 x2,
CNSl.7
x3.0
and
detach
0-D
1 (Mirror base plate) from The Mirror box.
14. Peel
off
B55 (Bayonet seat covering A), B56 (Bayonet seat covering B), B57 (Bayonet seat covering
C),
B58(Bayonet scat covering
D)
and
take CNS2.3
x5
.0 x4, B2 (Mount), WS t=0.2 (-adj) x4
27:340
35170
