The diagnosis array is set up as follows:
Safety Monitor Diagnosis Array
"basic function range" and "sorted by OSSD"
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
000
16
1 state of monitor
2 state of OSSD1
3 state of OSSD2
4 number of devices not green, OSSD1
5 number of devices not green, OSSD2
6 device index 32, OSSD1
7 color of device 32, OSSD1
8 device index 33, OSSD1
9 color of device 33, OSSD1
……
68 device index 63, OSSD1
69 color of device 63, OSSD1
70 device index 32, OSSD2
71 color of device 32, OSSD2
……
132 device index 63, OSSD2
133 color of device 63, OSSD2
Safety Monitor Diagnosis Array
"enhanced function range" and "sorted by OSSD"
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
000
16
1 state of monitor
2 state of OSSD1
3 state of OSSD2
4 number of devices not green, OSSD1
5 number of devices not green, OSSD2
6 device index 32, OSSD1
7 color of device 32, OSSD1
8 device index 33, OSSD1
……
133 color of device 95, OSSD1
134 device index 32, OSSD2
……
261 color of device 95, OSSD2
