7.3 Quick setup
This menu enables a fast configuration of the AS-i network.
Pressing "OK" you switch to the submenu "Store AS-i Configuration".
"Store+Run"
With "OK" you store the current AS-i network configuration and the attached sla-
ves as the target configuration. The gateway changes into the protected operating
mode.
"Store+Prj Mode"
With "OK" you store the current AS-i network configuration and the attached sla-
ves. The gateway remains in the project mode.
By pressing the "ESC" button you leave this menu and switch back to the main
menu.
Warning: outputs may be reset!
WARNING:
OUTPUT MAY BE
RESET
STORE AS-I
CONFIGURATION
STORE + RUN
STORE + PRJ MODE
