10.1.6 Advanced Diagnostics Object
Class Code: 103 (0x67)
1 instance for each AS-i circuit
Error counter:
10.1.7 Short Command Interface Object
Class Code: 104 (0x68)
1 instance
Attribute
ID
Access
Rule
Name DeviceNet
Data Type
Default
Data Value
100 (0x64) get/set los (list of offline slaves) ULINT
101 (0x65) get error counters a ARRAY[32]
of USINT
102 (0x66) get error counters b ARRAY[32]
of USINT
Single- and A-Slaves
Index Error Counter
1Slave 1/1A
2Slave 2/2A
3Slave 3/3A
……
31 Slave 31/31A
B-Slaves
Index Error Counter
1Slave 1B
2Slave 2B
3Slave 3B
……
31 Slave 31B
Attribute
ID
Access
Rule
Name DeviceNet
Data Type
Default
Data Value
100 (0x64) get/set content
command
toggle-bit and as-i circuit
data
ARRAY[12] of USINT
[0]
[1]
[2 … 11]
