Pepperl+Fuchs VBG-EN-K20-D - Store Current Configuration to the AS-I Master

AS-Interface
Command Interface
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 24.4.2007
110
Result: See chapter 8.2.1 "Values for results"
To get the input data again, the T-bit has to be reset again.
8.5.2 Store current configuration to the AS-i master
1. Switch master to configuration mode
2. Write the current slave configuration to the master
3. Switch master to protected mode
4. Wait until master is in normal (protected) operation mode
12-byte management
1. Switch master to config mode
Byte 12 00
hex
Response
Byte 1 50
hex
Byte 2 80
hex
(toggle bit, master1)
Byte 3 16-bit channel 1 high byte
hex
Byte 4 16-bit channel 1 low byte
hex
Byte 5 16-bit channel 2 high byte
hex
Byte 6 16-bit channel 2 low byte
hex
Byte 7 16-bit channel 3 high byte
hex
Byte 8 16-bit channel 3 low byte
hex
Byte 9 16-bit channel 4 high byte
hex
Byte 10 16-bit channel 4 low byte
hex
Byte 11 00
hex
not used
Byte 12 00
hex
not used
Request: SET_OP_MODE
Byte 1 0C
hex
(SET_OP_MODE)
Byte 2 00
hex
(T = 0, master 1, single master)
Byte 3 01
hex
(= config mode)
Byte 4 00
hex
……
Byte 12 00
hex
Response
Byte 1 00
hex
(or old values)
Byte 2 00
hex
(or old values)
……
Byte 12 00
hex
(or old values)
Request
