AS-Interface
EtherNet/IP Interface
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 24.4.2007
126
Common Services
10.1.2 Assembly Object
Class Code 4 (0x04)
Number of instances: 72
The Assembly Object bundles data from the application objects.
The Assembly Object Instances consist of (in case of a double master):
• A-slaves and/or single slaves from circuit 1
• Single, A- and B-slaves (all slaves) from circuit 1
• A-slaves and/or single slaves from both circuits
• Single, A- and B-slaves (all slaves) from both circuits
• No 16-bit data
• 16-bit data from slaves 29 … 31 from circuit 1
• 16-bit data from slaves 29 … 31 from both circuits
• No command interface
• Short command interface
• Long command interface
Instances 100 (0x64) … 135 (0x87) can only be read, while instances 136
(0x88) … 171 (0xAB) can be read and written.
Service Code Class Instance Service Name
0x05 no yes Code 1
(Class + Instance)
0x10 yes yes Get Attributes All
0x0E yes yes Get Attributes All
Attribute ID Access Rule Name Data Value
3 Data Item(s)
