AS-i EtherNet/IP Gateway
EtherNet/IP Interface
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 24.4.2007
127
Assembly Instance Data Item
Input Output
Size
(Byte)
Digital Analog
Command
interface
100 (0x64) 136 (0x88) 16 AS-i circuit 1,
Single- and A-slaves
101 (0x65) 137 (0x89) 28 AS-i circuit 1,
Single- and A-slaves
short
102 (0x66) 138 (0x8A) 52 AS-i circuit 1,
Single- and A-slaves
long
103 (0x67) 139 (0x8B) 40 AS-i circuit 1,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 ... 31
104 (0x68) 140 (0x8C) 52 AS-i circuit 1,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 ... 31
short
105 (0x69) 141 (0x8D) 76 AS-i circuit 1,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 ... 31
long
106 (0x6A) 142 (0x8E) 64 AS-i circuit 1,
Single- and A-slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
107 (0x6B) 143 (0x8F) 76 AS-i circuit 1,
Single- and A-slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
short
108 (0x6C) 144 (0x90) 100 AS-i circuit 1,
Single- and A-slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
long
109 (0x6D) 145 (0x91) 32 AS-i circuit 1,
all slaves
110 (0x6E) 146 (0x92) 44 AS-i circuit 1,
all slaves
short
111 (0x6F) 147 (0x93) 68 AS-i circuit 1,
all slaves
long
112 (0x70) 148 (0x94) 56 AS-i circuit 1,
all slaves
AS-i circuit 1,
Analog slaves 29 ... 31
113 (0x71) 149 (0x95) 68 AS-i circuit 1,
all slaves
AS-i circuit 1,
Analog slaves 29 ... 31
short
114 (0x72) 150 (0x96) 92 AS-i circuit 1,
all slaves
AS-i circuit 1,
Analog slaves 29 ... 31
long
115 (0x73) 151 (0x97) 80 AS-i circuit 1,
all slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
116 (0x74) 152 (0x98) 92 AS-i circuit 1,
all slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
short
117 (0x75) 153 (0x99) 116 AS-i circuit 1,
all slaves
AS-i circuite 1+2,
Analog slaves 29 ... 31
long
118 (0x76) 154 (0x9A) 32 AS-i circuite 1+2,
Single- and A-slaves
119 (0x77) 155 (0x9B) 44 AS-i circuite 1+2,
Single- and A-slaves
short
120 (0x78) 156 (0x9C) 68 AS-i circuite 1+2,
Single- and A-slaves
long
121 (0x79) 157 (0x9D) 56 AS-i circuite 1+2,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 .. 31
122 (0x7A) 158 (0x9E) 68 AS-i circuite 1+2,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 ... 31
short
123 (0x7B) 159 (0x9F) 92 AS-i circuite 1+2,
Single- and A-slaves
AS-i circuit 1,
Analog slaves 29 ... 31
long
