7.10.2 Safety monitor
The AS-i safety monitor reads the diagnosis data of the AS-i safety monitor and
shows on the display. The meaning of the shown diagnosis can be seen in the de-
scription of the safety monitor.
7.10.3 Safety Subst Value
With this function the input-data-substitution by safety slaves can be turn off/on.
SUBSTITUTE
The input-data are replaced mit following values:
Both channels released: 0000bin
Channel 1 released: 0011bin
Channel 2 released: 1100bin
No channel has released: 1111bin
NO SUBSTITUTE
The safety slave input data are shown unmodified.
SAFETY MONITOR
DIAGNOSIS
ADDR: 17
MODE: SORTED/V1
STATUS: O.K.
CH.1: OFF
CH.2: OFF
1-32: GREEN
...
SAFETY SUBST VAL
SUBSTITUTE
CHANGE
