AS-i EtherNet/IP Gateway
Operating in Advanced Display Mode
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 24.4.2007
43
7.7.2 IO + Param. Test (Testing AS-i In- and Outputs as well as reading and
writing AS-i Parameters)
Before changing to the menu the following warning message will displayed:
"Warning: Outputs may be set and Host may lose control."
The menu "IO + Param.Test" enables you to choose one of the following subme-
nus:
• Binary Inputs
• Binary Outputs
• Analog Inputs
• Analog Outputs
• Parameter
7.7.3 Binary input
This list shows the state of the binary inputs for all AS
-i slaves.
0: Input deleted
1: Input set
WARNUNG
OUTPUTS MAY BE
SET AND HOST MAY
LOSE CONTROL.
BINARY INPUTS
BINARY OUTPUTS
ANALOG INPUTS
ANALOG OUTPUTS
BINARY INPUTS
D3...D0
1A - 0 1 0 1
2A - 0 1 0 1
3A - 0 0 0 1
