8.3.5.13 Get permanent parameter (GET_PP)
With this call, a slave-specific parameter value stored on the EEPROM of the AS-i/
EtherNet/IP Gateway is read.
Meaning of bit B:
B = 0 Single AS-i slave or A-slave
B = 1 B-slave
8.3.5.14 Set auto address enable (SET_AAE)
This call can enable or disable the "automatic address programming" function.
The AUTO_ADDR_ENABLE bit is stored permanently; in other words, it is re-
tained after a warm/hot restart on the AS-i master.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
101
16
2T – circuit
3 – B slave address
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
101
16
2T result
3– PP
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
10B
16
2T – circuit
3 Auto_Address_Enable
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
10B
16
2T result
