Not permissible for other formwork
systems.
Shaft Corner TRIO 330
(Fig. A11.01)
Pos. Components Item no.
89 Shaft Corner TRIO 330 129945
89.6 Hole of the lug
Horizontally pre-assemble the shaft
formwork. (Fig. A17.0 9a)
Fig. A17.0 8
Do not attach the crane hook
into the lug hole (89.6)!
(Fig. A17.08a)
Fig. A17.0 8a
A17 Shaft formwork
TRIO Panel Formwork
Instructions for Assembly and Use – Standard Configuration
