VR2 CONTROL SYSTEM
SK77898/2
PG DRIVES TECHNOLOGY
86
VR2
INDICATORS
LIGHTS
GND
INDICATORS
LIGHTS
GND
112332
1 2
LIGHTING MODULE WIRING DETAIL
LOOKING AT LIGHTING MODULE
Connection
Pin1
Pin2
Pin3
Ground
Lights
Indicators
Function
123
