Parts Lists and
Assembly
Diagrams
Final Assembly Parts Lists catalog the parts that are specific to a version of
the LIFEPAK 500 AED.
Replacement Kits list the parts supplied for service repair purposes.
Common Accessories table lists part numbers for separate accessories for use
with the LIFEPAK 500 AED.
Page 2 of 2 Assembly Diagrams show components of the LIFEPAK 500 AED as they are
installed in an AED final assembly. Each Assembly Diagram depicts a different
view of the AED. Numbered callouts identify the individual AED components.
Clicking on a number associated with a callout triggers one of two actions:
■ Selecting a callout for a component that is common to all versions of the
AED jumps to a parts list where the desired component part number can be
identified.
■ Selecting a callout for a component that is unique to a specific version of the
AED (e.g., language specific labels) jumps to the Final Assembly Parts
listing where the desired component part number can be identified.
