LIFEPAK 500 automated external defibrillator Parts Lists and Assembly Diagrams
12-64
Wire Routing and Tie-Wrap Placement—Biphasic AED
22 (3×)
21 (5×)
23
Connectors shown in relative position on underside
of the main PCB, which is not shown.
White
to J3
Red to J2
Red to J4
21 (REF)
Ferrite
Bead
(REF)
P3
P4
P2
Shield
Capacitor
To J105
To J16-1
To J101
To J16-5
White
wires
Red
wires
