LIFEPAK 500 automated external defibrillator Product Description
3-9
System Context Diagram
The system context diagram
shows you how the LIFEPAK
500 AED connects to a variety
of devices, including the
battery paks, the PC interface
cable, the Setup Transfer
Cable, and the QUIK-COMBO
pacing/defibrillation/ECG
electrodes and FAST-PATCH
electrodes.
LIFEPAK 500
AED
QUIK-COMBO
pacing/
defibrillation/
ECG electrodes
or FAST-PATCH
disposable
defibrillation/ECG
electrodes
AED to PC
Interface
Cable
PN 3005381-000
AED to Modem
Interface Cable
PN 3005381-001
AED to Printer
Interface Cable
PN 3005381-002
QUIK-COMBO
Clinical Extension
Cable
PN 3011215-000
Test Load
PN 3005389-000
Computer
Serial
Port
Hayes
Compatible
Modem
EPSON
LX-300
Compatible
Printer
QUIK-COMBO
Test Post
Adapter
PN 3005302-00
Patient
SLA battery
charger
PN 3006535
LIFEPAK 500
rechargeable
SLA battery pak
PN 3005379
LIFEPAK 500
nonrechargeable
lithium sulpher
dioxide battery pak
PN 3005380
Choose battery type based upon
intended AED usage.
LIFEPAK 500
AED
AED to AED
Setup Transfer
Cable
PN 3010779-000
You can attach any of these devices, one at a time, to the
LIFEPAK 500 AED patient connector.
LIFEPAK 500
nonrechargeable
lithium manganese
dioxide battery pak
PN 3200390
