LIFEPAK 500 automated external defibrillator Parts Lists and Assembly Diagrams
12-6
Parts Lists
Service Kits
Item Quantity Part Number Part Description Note
1 3010399-000 Kit – Replacement, Case
Used on monophasic units
a
1 3010399-001 Kit – Replacement, Battery Plate Used on all units
1 3010399-002 Kit – Replacement, U.S. Domestic Labels,
3-Button Unit
Used on monophasic units
1 3010399-003 Kit – Replacement, Capacitor Used on monophasic units
1 3010399-004 Kit – Replacement, Inductor Used on monophasic units
1 3010399-005 Kit – Replacement, Main PCB Installation
Components
Used on all units
1 3010399-006 Kit – Replacement, QUIK-COMBO Connector Used on monophasic units
1 3010399-007 Kit – Replacement, Capacitor Wires Used on monophasic units
1 3010399-013 Kit – Replacement, Main PCB, English Used on monophasic units
W01 1 3010399-014 Kit – Replacement, Speaker Used on all units
1 3010399-015 Kit – Replacement, Case, Without Readiness
Display
Used on biphasic units
1
a. Order product labels separately. Refer to the appropriate Final Assembly Parts List for the AED under repair.
Label Replacement Kit for U.S. Domestic Units only.
