LIFEPAK 500 automated external defibrillator Parts Lists and Assembly Diagrams
12-31
Parts Lists
LIFEPAK 500 Monophasic and Biphasic AED Miscellaneous Replacement Items
Item Quantity Part Number Part Description References
11 2 200363-031 Rivet - Push, .1 × .177L
9 17 202253-570 #6-32 × .375L PH Screw
12 5 3005344-000 Alps Cap Switch
15 1 3005358-000 Patient Connector Door
W02 1 3005361-002 Battery Plate Wire Harness
21 5 200536-008 Self-Locking Nylon Cable Tie Retainer
23 1 3009897-000 Shield - Wire Harness
7 4 802885-01 Mounting Foot
20 1 804234-02 Perimeter Seal
Ref 1 202305-000 Clock Battery, Lithium
