LIFEPAK 500 automated external defibrillator Product Description
3-6
Physical Description and Features Page 5 of 7
Number Description
7 The speaker provides audio voice prompts and tones.
8 The battery compartment accommodates a single removable
battery pak that provides power for the AED.
9 The Liquid Crystal Display (LCD) provides operating messages
on two 20-character lines.
10 The
RIGHT ARROW key is used to set the clock, transfer data, and
select options.
11 The
UP ARROW KEY is used to set the clock, transfer data, and
select options.
12 The
LOW BATTERY indicator is a red backlit icon that indicates the
AED battery is low. If the indicator is lit and the AED displays the
LOW BATTERY message, the battery is low. If the indicator
flashes on and off and the AED displays the REPLACE
BATTERY message, the battery is very low. Replace the battery
immediately.
13 The
SERVICE indicator is a red backlit icon that indicates the AED
requires service by authorized service personnel.
14
(optional)
The blank “menu” key allows a change of setup options in units
without an
ANALYZE key.
