LIFEPAK 500 automated external defibrillator Troubleshooting
8-19
Fault Code Table Page 16 of 20
Code Fault Description
Corrective
Action
Code
9115 boot_defib_task_init_failure 10
9116 boot_cmon_task_init_failure 10
9117 boot_iv_bus_error 10
9118 boot_iv_address_error 10
9119 boot_iv_illegal_instruction 10
911a boot_iv_zero_divide 10
911b boot_iv_privilege_violation 10
911c boot_unexpected_interrupt 10
911d boot_rtc_oscillator_failure 9, 2
9400 dsp_comm_fault_major 10
9401 dsp_not_initializing 10, 2
9402 dsp_code_download_failed 10, 2
9403 dsp_comm_timeout_no_data_recvd 10
9404 dsp_comm_bad_packet_detected 10
9600 analyze_fault_major 10
9601 sas_task_waveforms_absent 10
9700 control_fault_major 10
9703 control_start_lead_status_timer_failed 10
9704 control_lead_status_update_timeout 10
Corrective Action Code Key
Code Description
1 Try to reload the software
2 Replace the Main PCB
3 Replace the Connector
4 Replace the Energy Storage Capacitor
5 Replace the Inductor
6 Recalibrate/Restore Setup, Complete PIP,
Return to service if fault codes do not recur
7 Check the Wires
8 Check the Battery
9 Replace the Time-of-Day Clock Battery
10 Clear Faults, Complete PIP, Return to service
if fault codes do not recur
11 Replace the Biphasic PCB
