12 • Maintenance
SV62261 Rev. C
Removing the Shield and Wick (DM300c)
1. Pull up and remove the shield and wick from the moistener.
Wick
Shield
6. Slide the moistener back onto the machine. You should hear a
click as it engages.
Maintaining the Moistener (cont'd)
CLICK!
2. Separate the wick from the shield. Clean the wick in plain water,
and rinse thoroughly. Blot the excess water from the wick.
i
NOTE: Replace the wick and shield if they cannot be cleaned
thoroughly.
3. Place the wick back into the shield.
4. Push the wick and shield back into moistener tank. Be sure that the
underside of the shield is in contact with the top of the wick. Press
fi rmly on both ends of the shield to make sure it snaps into place.
5. Reinstall the moistener. Push down on the blue re lease lever on
the moistener.
Release Lever
i
NOTE: This procedure assumes you have already removed the
moistener (see previous section).
