Pitney Bowes DM300C - Parts of the Machine - DM475

2-6
2 • Getting to Know Your System
SV62261 Rev. C
Parts of the Machine - DM475
1
2
3
4
5
10
16
11
13
15
(shown with optional
weighing platform)
14
8
12
Item Part Description
1
Feeder/WOW
Cover
Open this cover to gain access to the WOW deck
and two clearance levers (items #16 and #17)
2
Seal/No Seal
Lever
Allows you to turn envelope sealing on and off
3
Sealing Fluid
Level Indicator
Allows you to see how much sealing fluid is left in
the tank (red band indicates low level)
4
Tape Feeder Holds and feeds tape strips for printing
5
Weighing
Platform
(optional)
Allows you to weigh a mail piece so your system
can calculate postage based on the service
selected
6
Ink Access
Cover (under
optional scale)
Opens up to allow replacement of the ink
cartridge (see Chapter 12, Maintenance)
7
6
9
17
(shown with
cover open)
