2 • Getting to Know Your System
SV62261 Rev. C
7
Ink Waste Tank
(in tray under
printer section)
Collects ink waste
8
Stacker Tray
Storage Slot
Allows you store the Quick Reference Guide, CD,
etc. for easy access.
9
Stacker Tray Allows the neat stacking of finished mail pieces
10
Control Panel Allows you to enter and set up information on
your machine (see next page for details)
11
Printer
Clearance
Lever (two
position)
Home - printer rollers engaged for processing
mail (normal)
Released - printer rollers disengaged; lower
portion of printer deck drops down so you can
clear a stalled mail piece
i
NOTE: The machine won't process mail
when the lever is left in the released position.
12
Printer Deck Supports your mail piece or tape strip as it
passes un der the printer mechanism
13
Feeder/WOW
Deck
Supports your mail piece as it feeds through the
feeder/WOW section
14
Moistener Applies sealing fluid to the envelope flap (you
can seal envelopes or leave them unsealed,
depending on the position of Seal/No Seal lever)
15
Side Guide Reduces the skewing of pieces of mail as you
feed them into the feeder.
16
Moistener
Clearance
Lever (two
position, under
cover)
Home - printer rollers engaged for processing
mail (normal)
Released - printer rollers disengaged; upper
rollers lifted so you can clear a stalled mail piece
i
NOTE: The machine won't process mail
when the lever is left in the released position.
17
Feeder/WOW
Clearance Lever
(two position,
under cover)
Home - transport rollers engaged for processing
mail (normal)
Released - transport rollers disengaged; upper
rollers lifted so you can clear a stalled mail piece
i
NOTE: The machine won't process mail
when the lever is left in the released position.
Parts of the Machine - DM475 (cont'd)
To Next Page
