User’s Manual of MGSW-24160F

201

UDP: Select UDP to filter IPv4 UDP protocol frames. Extra fields for defining

UDP parameters will appear. These fields are explained later in this help file.

TCP: Select TCP to filter IPv4 TCP protocol frames. Extra fields for defining TCP

parameters will appear. These fields are explained later in this help file.

 IP Protocol Value

When "Specific" is selected for the IP protocol value, you can enter a specific

value. The allowed range is 0 to 255. A frame that hits this ACE matches this IP

protocol value.

 IP TTL

Specify the Time-to-Live settings for this ACE.

zero: IPv4 frames with a Time-to-Live field greater than zero must not be able to

match this entry.

non-zero: IPv4 frames with a Time-to-Live field greater than zero must be able to

match this entry.

Any: Any value is allowed ("don't-care").

 IP Fragment

Specify the fragment offset settings for this ACE. This involves the settings for the

More Fragments (MF) bit and the Fragment Offset (FRAG OFFSET) field for an

IPv4 frame.

No: IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater

than zero must not be able to match this entry.

Yes: IPv4 frames where the MF bit is set or the FRAG OFFSET field is greater

than zero must be able to match this entry.

Any: Any value is allowed ("don't-care").

 IP Option

Specify the options flag setting for this ACE.

No: IPv4 frames where the options flag is set must not be able to match this

entry.

Yes: IPv4 frames where the options flag is set must be able to match this entry.

Any: Any value is allowed ("don't-care").

 SIP Filter

Specify the source IP filter for this ACE.

Any: No source IP filter is specified. (Source IP filter is "don't-care".)

Host: Source IP filter is set to Host. Specify the source IP address in the SIP

Address field that appears.

Network: Source IP filter is set to Network. Specify the source IP address and

source IP mask in the SIP Address and SIP Mask fields that appear.

 SIP Address

When "Host" or "Network" is selected for the source IP filter, you can enter a

specific SIP address in dotted decimal notation.

 SIP Mask

When "Network" is selected for the source IP filter, you can enter a specific SIP

mask in dotted decimal notation.

 DIP Filter

Specify the destination IP filter for this ACE.

Any: No destination IP filter is specified. (Destination IP filter is "don't-care".)

Host: Destination IP filter is set to Host. Specify the destination IP address in the

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
