User’s Manual of MGSW-24160F

202

DIP Address field that appears.

Network: Destination IP filter is set to Network. Specify the destination IP

address and destination IP mask in the DIP Address and DIP Mask fields that

appear.

 DIP Address

When "Host" or "Network" is selected for the destination IP filter, you can enter a

specific DIP address in dotted decimal notation.

 DIP Mask

When "Network" is selected for the destination IP filter, you can enter a specific

DIP mask in dotted decimal notation.

 ICMP Parameters

Object Description

 ICMP Type Filter

Specify the ICMP filter for this ACE.

Any: No ICMP filter is specified (ICMP filter status is "don't-care").

Specific: If you want to filter a specific ICMP filter with this ACE, you can enter a

specific ICMP value. A field for entering an ICMP value appears.

 ICMP Type Value

When "Specific" is selected for the ICMP filter, you can enter a specific ICMP

value. The allowed range is 0 to 255. A frame that hits this ACE matches this

ICMP value.

 ICMP Code Filter

Specify the ICMP code filter for this ACE.

Any: No ICMP code filter is specified (ICMP code filter status is "don't-care").

Specific: If you want to filter a specific ICMP code filter with this ACE, you can

enter a specific ICMP code value. A field for entering an ICMP code value

appears.

 ICMP Code Value

When "Specific" is selected for the ICMP code filter, you can enter a specific

ICMP code value. The allowed range is 0 to 255. A frame that hits this ACE

matches this ICMP code value.

 TCP/UDP Parameters

Object Description

 TCP/UDP Source Filter

Specify the TCP/UDP source filter for this ACE.

Any: No TCP/UDP source filter is specified (TCP/UDP source filter status is

"don't-care").

Specific: If you want to filter a specific TCP/UDP source filter with this ACE, you

can enter a specific TCP/UDP source value. A field for entering a TCP/UDP

source value appears.

Range: If you want to filter a specific TCP/UDP source range filter with this ACE,

you can enter a specific TCP/UDP source range value. A field for entering a

TCP/UDP source value appears.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
