Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
216
communication between the switch and the client, so this will not detect whether
the client is still attached or not, and the only way to free any resources is to age
the entry.
 Hold Time
This setting applies to the following modes, i.e. modes using the Port Security
functionality to secure MAC addresses:
Single 802.1X
Multi 802.1X
MAC-Based Auth.
If a client is denied access - either because the RADIUS server denies the client
access or because the RADIUS server request times out (according to the
timeout specified on the "Configuration→Security→AAA" page) - the client is put
on hold in the Unauthorized state. The hold timer does not count during an
on-going authentication.
In MAC-based Auth. mode, the The switch will ignore new frames coming from
the client during the hold time.
The Hold Time can be set to a number between 10 and 1000000 seconds.
 RADIUS-Assigned QoS
Enabled
RADIUS-assigned QoS provides a means to centrally control the traffic class to
which traffic coming from a successfully authenticated supplicant is assigned on
the switch. The RADIUS server must be configured to transmit special RADIUS
attributes to take advantage of this feature (see RADIUS-Assigned QoS Enabled
bel
ow for a detailed description).
The "RADIUS-Assigned QoS Enabled" checkbox provides a quick way to
globally enable/disable RADIUS-server assigned QoS Class functionality. When
checked, the individual ports' ditto setting determines whether RADIUS-assigned
QoS Class is enabled for that port. When unchecked, RADIUS-server assigned
QoS Class is disabled for all ports.
 RADIUS-Assigned
VLAN Enabled
RADIUS-assigned VLAN provides a means to centrally control the VLAN on
which a successfully authenticated supplicant is placed on the switch. Incoming
traffic will be classified to and switched on the RADIUS-assigned VLAN. The
RADIUS server must be configured to transmit special RADIUS attributes to take
advantage of this feature (see RADIUS-Assigned VLAN Enabled below for a
det
ailed description).
The "RADIUS-Assigned VLAN Enabled" checkbox provides a quick way to
globally enable/disable RADIUS-server assigned VLAN functionality. When
checked, the individual port’s ditto setting determines whether RADIUS-assigned
VLAN is enabled for that port. When unchecked, RADIUS-server assigned VLAN
is disabled for all ports.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
