User’s Manual of MGSW-24160F

217

 Guest VLAN Enabled

A Guest VLAN is a special VLAN - typically with limited network access - on

which 802.1X-unaware clients are placed after a network administrator-defined

timeout. The switch follows a set of rules for entering and leaving the Guest

VLAN as listed below.

he "Guest VLAN Enabled" checkbox provides a quick way to globally

enable/disable Guest VLAN functionality. When checked, the individual ports'

ditto setting determines whether the port can be moved into Guest VLAN. When

unchecked, the ability to move to the Guest VLAN is disabled for all ports.

 Guest VLAN ID

This is the value that a port's Port VLAN ID is set to if a port is moved into the

Guest VLAN. It is only changeable if the Guest VLAN option is globally enabled.

alid values are in the range [1; 4095].

 Max. Reauth. Count

The number of times that the switch transmits an EAPOL Request Identity frame

without response before considering entering the Guest VLAN is adjusted with

this setting. The value can only be changed if the Guest VLAN option is globally

ena

bled.

Valid values are in the range [1; 255].

 Allow Guest VLAN if

EAPOL Seen

The switch remembers if an EAPOL frame has been received on the port for the

lifetime of the port. Once the switch considers whether to enter the Guest VLAN,

it will first check if this option is enabled or disabled. If disabled (unchecked;

default), the switch will only enter the Guest VLAN if an EAPOL frame has not

been received on the port for the lifetime of the port. If enabled (checked), the

switch will consider entering the Guest VLAN even if an EAPOL frame has been

received on the port for the lifetime of the port.

The value can only be changed if the Guest VLAN option is globally enabled.

Port Configuration

The table has one row for each port on the selected switch and a number of columns, which are:

Object Description

 Port

The port number for which the configuration below applies.

 Admin State

If NAS is globally enabled, this selection controls the port'

s authentication mode.

The following modes are available:

Force Authorized

In this mode, the switch will send one EAPOL Success frame when the port link

comes up, and any client on the port will be allowed network access without

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
