User’s Manual of MGSW-24160F

221

the RADIUS-assigned).

This option is only available for single-client modes, i.e.

• Port-based 802.1X

• Single 802.1X

RADIUS attributes used in identifying a QoS Class:

Refer to the written documentation for a description of the RADIUS attributes

needed in order to successfully identify a QoS Class. The User-Priority-Table

attribute defined in RFC4675 forms the basis for identifying the QoS Class in an

Access-Accept packet.

Only the first occurrence of the attribute in the packet will be considered, and to

be valid, it must follow this rule:

All 8 octets in the attribute's value must be identical and consist of ASCII

characters in the range '0' - '3', which translates into the desired QoS Class in the

range [0; 3].

 RADIUS-Assigned

VLAN Enabled

- When RADIUS-Assigned VLAN is both globally enabled and enabled

(checke

d) for a given port, the switch reacts to VLAN ID information

carried in the RADIUS Access-Accept packet transmitted by the

RADIUS server when a supplicant is successfully authenticated. If

present and valid, the port's Port VLAN ID will be changed to this VLAN

ID, the port will be set to be a member of that VLAN ID, and the port will

be forced into VLAN unaware mode. Once assigned, all traffic arriving

on the port will be classified and switched on the RADIUS-assigned

VLAN ID.

If (re-)authentication fails or the RADIUS Access-Accept packet no

longer carries a VLAN ID or it's invalid, or the supplicant is otherwise no

longer present on the port, the port's VLAN ID is immediately reverted to

the original VLAN ID (which may be changed by the administrator in the

meanwhile without affecting the RADIUS-assigned).

This option is only available for single-client modes, i.e.

• Port-based 802.1X

• Single 802.1X

For trouble-shooting VLAN assignments, use the

"Monitor→VLANs→VLAN Membership and VLAN Port" pages. These

pages show which modules have (temporarily) overridden the current

Port VLAN configuration.

RADIUS attributes used in identifying a VLAN ID:

RFC2868 and RFC3580 form the basis for the attributes used in identifying a

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990
