Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
227
received by the switch.
Rx
Logoff
dot1xAuthEapolLogoffFr
amesRx
The number of valid EAPOL
Logoff frames that have
been received by the switch.
Rx
Invalid Type
dot1xAuthInvalidEapolF
ramesRx
The number of EAPOL
frames that have been
received by the switch in
which the frame type is not
recognized.
Rx
Invalid Length
dot1xAuthEapLengthErr
orFramesRx
The number of EAPOL
frames that have been
received by the switch in
which the Packet Body
Length field is invalid.
Tx
Total
dot1xAuthEapolFrames
Tx
The number of EAPOL
frames of any type that has
been transmitted by the
switch.
Tx
Request ID
dot1xAuthEapolReqIdFr
amesTx
The number of EAPOL
Request Identity frames that
have been transmitted by
the switch.
Tx
Requests
dot1xAuthEapolReqFra
mesTx
The number of valid EAPOL
Request frames (other than
Request Identity frames)
that have been transmitted
by the switch.
These backend (RADIUS) frame counters are available for the following administrative
states:
Port-based 802.1X
Single 802.1X
Multi 802.1X
MAC-based Auth.
 Backend Server
Counters
Direction Name IEEE Name Description

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
