Planet MGSW-24160F User Manual

User’s Manual of MGSW-24160F
228
Rx
Access
Challenges
dot1xAuthBackendAcce
ssChallenges
802.1X-based:
Counts the number of times
that the switch receives the
first request from the backend
server following the first
response from the supplicant.
Indicates that the backend
server has communication
with the switch.
MAC-based:
Counts all Access Challenges
received from the backend
server for this port (left-most
table) or client (right-most
table).
Rx
Other
Requests
dot1xAuthBackendOther
RequestsToSupplicant
802.1X-based:
Counts the number of times
that the switch sends an EAP
Request packet following the
first to the supplicant.
Indicates that the backend
server chose an EAP-method.
MAC-based:
Not applicable.
Rx
Auth.
Successes
dot1xAuthBackendAuth
Successes
802.1X- and MAC-based:
Counts the number of times
that the switch receives a
success indication. Indicates
that the supplicant/client has
successfully authenticated to
the backend server.
Rx
Auth.
Failures
dot1xAuthBackendAuth
Fails
802.1X- and MAC-based:
Counts the number of times
that the switch receives a
failure message. This
indicates that the
supplicant/client has not
authenticated to the backend

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
