2. Install the mounting plate on the gas pipe. Rest of the work will be done on the object.
Place the second cutting ring and sealable nut
opposite side – thread to the left side of plate
Align device onto plate to fit with the mounting holes with rivet nuts.
Use the attached screws M5x12 to attach the device to plate.
Remember to use proper mounting plate kit designed for
the specific version of device. Wrong type of the plate can
cause shown incompatibilities
