Porsche Wallbox - Technical Data

Technical Data | GB
45
Technical Data
Electrical data
Porsche Wallbox
PWB22E212
Porsche Wallbox
PWB22E213
Porsche Wallbox in acc. w. the calibra-
tion law
PWB221E223
Power 22kW 22kW 22kW
Rated current 32 A 32 A 32 A
Mains voltage 220-240/380-415 V 220-240/380-415 V 230/400 V
Mains frequency 50/60 Hz 50/60 Hz 50/60 Hz
Charging power mode 3 22kW 22kW 22kW
Charging current mode 3 3 x 32 A 3 x 32 A 3 x 32 A
Mains connection 3P, N, PE 3P, N, PE 3P, N, PE
Overvoltage category (IEC 60664) III III III
Integrated residual current operated de-
vice
IΔN 6mA DC IΔN 6mA DC IΔN 6mA DC
Vehicle plug Type 2 Type 2 Type 2
Rated impulse withstand voltage Uimp. 4kV 4kV 4kV
Rated insulation voltage 500 V 500 V 500 V
Rated current of the switch gear combi-
nation
32 A 32 A 32 A
Conditional rated short-circuit current Icc 3kA 3kA 3kA
Rated load factor RDF 1 1 1
