Chapter 2 Specifications
2-3
2.1.3 Structural
Grounding 100Ω or less, or your country's applicable standard
Ratings
*1
(For front panel of installed unit)
*1 The front face of the ST unit, installed in a solid panel, has been tested using conditions equivalent
to the standards shown in the specification.
Therefore, prior to installing the ST be sure to confirm the type of conditions that will be present
in the ST's operating environment. If the installation gasket is used for a long period of time, or
if the unit and its gasket are removed from the panel, the original level of the protection cannot
be guaranteed. To maintain the original protection level, be sure to replace the installation gasket
regularly.
Equivalent to IP65 (JEM 1030), NEMA#250 Type4X/12
External Dimensions W130 mm [5.12 in] x H104 mm [4.09 in] x D41 mm [1.61 in]
Weight 0.4Kg (0.9lb) or less
Cooling Method Natural air circulation
