ST Series User’s Manual
2-14
2.5.2 Panel Cut Dimensions
2.5.3 Installation Fasteners
Unit: mm [in.]
118.5
+1
0
[4.67
+0.04
]
0
92.5
+1
[3.64
+1
]
0 0
Under 4-R3
F1
F2
F3
F4
F5
F6
11
[0.43]
16[0.63]
φ10
[0.39]
31[1.22]
M6
16.6[0.65]
Unit:mm[in]
