Chapter 2 Specifications
2-7
ST403-AG41-24V
Network Interface (X) Ethernet(IEEE802.3) 10BASE-T
Serial I/F(Y)
Asynchronous Transmission: RS-232C/RS-422
Data Length: 7 or 8 bits
Stop Bit: 1 or 2 bits
Parity: None, Odd or Even
Data Transmission Speed: 2,400bps to 115,200bps
Tool Connector (TOOL)
Asynchronous TTL level nonprocedural command I/F
<During screen file development>
Used for transferring data to and from the GP application software and
the ST.
<During Operation>
Used for a variety of devices, including a bar-code reader.
To Next Page
