Chapter 2 Specifications
2-13
2.5 Dimensions
2.5.1 ST Series External Dimensions
The following drawing shows the ST Series unit with installation fasteners.
118[4.65]
118[4.65]
Top
Top
Front
Front
Right Side
Right Side
104[4.09]
104[4.09]
5[0.20]
5[0.20]
41[1.61]
41[1.61]
Unit:mm[in.]
Unit:mm[in.]
130[5.12]
130[5.12]
92[3.62]
92[3.62]
F1
F1
F2
F2
F3
F3
F4
F4
F5
F5
F6
F6
129[5.08]
64.5[2.54]
139[5.47]
5[0.20]
41[1.61]
21.5[0.85]
43[1.69]
104[4.09]
Top
Front
Right Side
Unit:mm[in.]
F1
F1
F2
F2
F3
F3
F4
F4
F5
F5
F6
F6
