ST Series User’s Manual
2-4
2.2 Functional Specifications
2.2.1 Display
Type Monochrome LCD
Resolution 320 x 240 pixels
Active Display Area W76.7 mm [3.02in.] x H57.5 mm [2.26in.]
Colors
Black and White, 2 levels of gray/Black and White, 8 levels of
gray
*1
(Color switching is done via software)
*1 Depending on the color used, selecting MONOCHROME 8 HUES may cause the ST unit's screen
to flicker and make it difficult to distinguish colors. Confirm that all colors display as expected prior
to using this mode.
Backlight
ST400-AG41-24V
ST401-AG41-24V
ST402-AG41-24V
LED Backlight
(Color: Amber
*2
; Service life: Ave. 50,000 hrs.
[half of original brightness])
*2 Among backlight units there may be slight variations in illumination color, however, this does not
effect the performance or quality of the ST unit.
ST403-AG41-24V
LED Backlight
(Color: Amber
*2
; Service life: Ave. 50,000 hrs.
[half of original brightness])
(Color: Red
*2
; Service life: Ave. 10,000 hrs.
[half of original brightness])
Contrast Adjustment 8 levels of adjustment available via touch panel.
Brightness Adjustment 2 levels of adjustment available via touch panel.
Language Fonts
ASCII: (Code page 850) Alphanumeric (incl. Eur. characters)
Chinese: (GB2312-80 codes) simplified Chinese fonts
Japanese: ANK 158, Kanji : 6,962 (JIS Standards 1 & 2)
(including 607 non-kanji characters)
Korean: (KSC5601 - 1992 codes) Hangul fonts
Taiwanese: (Big 5 codes) traditional Chinese fonts
Character
Character Sizes
*3
*3 The display font will differ depending on which (language) character, or which size you select. Also,
if GP-PRO/PBIII Ver. 5.0 or later software is used, high quality fonts are available with 16x16 or
larger characters.
6.9 Font Setting (Page 6-30)
8X8, 8X16, 16X16 and 32X32 dot fonts
Font Sizes
Width can be expanded 1 to 8 times.
Height can be expanded 1/2 and 1 to 8 times.
Text
8x8 dots 40 Char. x 30 rows
8x16 dots 40 Char. x 15 rows
16x16 dots 20 Char. x15 rows
32x32 dots 10 Char. x 7 rows
SEE
To Next Page
